Keithley 2601 Reference Manual

Table D-4
System node and SRQ enable register bit attributes
Attribute Description Bit
To set system node enable register bits:
status.node_enable = status.MEASUREMENT_SUMMARY_BIT
status.node_enable = status.MSB
status.node_enable = status.ERROR_AVAILABLE
status.node_enable = status.EAV
status.node_enable = status.QUESTIONABLE_SUMMARY_BIT
status.node_enable = status.QSB
status.node_enable = status.MESSAGE_AVAILABLE
status.node_enable = status.MAV
status.node_enable = status.EVENT_SUMMARY_BIT
status.node_enable = status.ESB
status.node_enable = status.MASTER_SUMMARY_STATUS
status.node_enable = status.MSS
status.node_enable = status.OPERATION_SUMMARY_BIT
status.node_enable = status.OSB
Enable MSB.
Enable MSB.
Enable EAV bit.
Enable EAV bit.
Enable QSB.
Enable QSB.
Enable MAV bit.
Enable MAV bit.
Enable ESB.
Enable ESB.
Enable MSS bit.
Enable MSS bit.
Enable OSB.
Enable OSB.
B0
B0
B2
B2
B3
B3
B4
B4
B5
B5
B6
B6
B7
B7
To set service request enable register bits:
status.request_enable = status.MEASUREMENT_SUMMARY_BIT
status.request_enable = status.MSB
status.request_enable = status.SYSTEM_SUMMARY_BIT
status.request_enable = status.SSB
status.request_enable = status.ERROR_AVAILABLE
status.request_enable = status.EAV
status.request_enable = status.QUESTIONABLE_SUMMARY_BIT
status.request_enable = status.QSB
status.request_enable = status.MESSAGE_AVAILABLE
status.request_enable = status.MAV
status.request_enable = status.EVENT_SUMMARY_BIT
status.request_enable = status.ESB
status.request_enable = status.OPERATION_SUMMARY_BIT
status.request_enable = status.OSB
Enable MSB.
Enable MSB.
Enable SSB.
Enable SSB.
Enable EAV bit.
Enable EAV bit.
Enable QSB.
Enable QSB.
Enable MAV bit.
Enable MAV bit.
Enable ESB.
Enable ESB.
Enable OSB.
Enable OSB.
B0
B0
B1
B1
B2
B2
B3
B3
B4
B4
B5
B5
B7
B7
To read registers:
print(status.node_enable)
print(status.request_enable)
print(status.condition)
Request system enable register.
Request SRQ enable register.
Request status byte register.
D-14 Return to Section Topics 2600S-901-01 Rev. C / January 2008
