D-26 Return to Section Topics 2600S-901-01 Rev. C / January 2008
Appendix D: Status Model Series 2600 System SourceMeter® Instruments Reference Manual
To set register bits:
status.measurement.instrument.smuX.* = status.measurement.VOLTAGE_LIMIT B0
status.measurement.instrument.smuX.* = status.measurement.VLMT B0
status.measurement.instrument.smuX.* = status.measurement.CURRENT_LIMIT B1
status.measurement.instrument.smuX.* = status.measurement.ILMT B1
status.measurement.instrument.smuX.* = status.measurement.READING_OVERFLOW B7
status.measurement.instrument.smuX.* = status.measurement.ROF B7
status.measurement.instrument.smuX.* = status.measurement.BUFFER_AVAILABLE B8
status.measurement.instrument.smuX.* = status.measurement.BAV B8
1. * = '.ntr', '.ptr' and '.enable'; smuX = smua or smub.
To read registers:
print(status.measurement.instrument.smuX.*)
print(status.measurement.instrument.smuX.condition)
print(status.measurement.instrument.smuX.event)
To set register bits:
status.measurement.instrument.* = status.measurement.instrument.SMUA B1
status.measurement.instrument.* = status.measurement.instrument.SMUB B2
To read registers:
print(status.measurement.instrument.*)
print(status.measurement.instrument.condition)
print(status.measurement.instrument.event)
To set register bits:
status.measurement.voltage_limit.* = status.measurement.voltage_limit.SMUA B1
status.measurement.voltage_limit.* = status.measurement.voltage_limit.SMUB B2
To read registers:
print(status.measurement.voltage_limit.*)
print(status.measurement.voltage_limit.condition)
print(status.measurement.voltage_limit.event)
To set register bits:
status.measurement.current_limit.* = status.measurement.current_limit.SMUA B1
status.measurement.current_limit.* = status.measurement.current_limit.SMUB B2
To read registers:
print(status.measurement.current_limit.*)
print(status.measurement.current_limit.condition)
print(status.measurement.current_limit.event)
To set register bits:
status.measurement.buffer_available.* = status.measurement.buffer_available.SMUA B1
status.measurement.buffer_available.* = status.measurement.buffer_available.SMUB B2
To read registers:
print(status.measurement.buffer_available.*)
print(status.measurement.buffer_available.condition)
Table D-9 (continued)
Operation event commands
Command
1
Bit
