Keithley 4200-SCS Startup Guide

8
Model 4200-SCS
Step 8 View data sheet
The data sheet for the “vds-id” test is displayed by clicking the Sheet tab for the test. Use the tabs at the
bottom of the Sheet to display the data type. A sample data sheet for the “vds-id” test is shown in Figure 8.
Figure 8: Sample data sheet for “vds-id” test
* To select more than one sheet for selective printing, hold down the Ctrl key and then click the tab. See
Step 10 to print Sheet data.
Click to display
Data sheet*.
Click to export
data (see Step 10).
Click to display
Calc sheet*.
Click to display
Settings sheet*.
