Keithley S530 Administrative Guide

Section 2: S530 site preparation and installation S530 Parametric Test System Administrative Guide
2-16
S530-924-01 Rev. D / September 2017
Figure 24: Example S530 System Installation Form page 3
System cabinet size and weight
The size and weight specifications for the system cabinet are listed in the next table. See Floor plan
(on page 2-20) for details about designing a floor plan for the system cabinet.
System cabinet size and weight
Size (width × depth × height)
Weight
Minimum configuration
Maximum configuration
601.47 mm × 914.40 mm × 1901.00 mm
(23.68 in. × 36.00 in. × 74.01 in.)
195.0 kg
(430 lb)
285.76 kg
(630 lb)
