S530/S540 KTE Linear Parametric Test Library (LPTLib) User's Manual Section 3: LPTLib c
ommand reference
S530-900-01 Rev. E / September 2017 3-27
S530/S540 instrument defaults after a devint command is called are shown in the following tables.
Source-measure unit (SMU) settings after a devint command (defaults)
Item 2410
(S530 systems only)
2636B 2657A
(S540 systems only)
rangei 1.05e-4 A 10e-3 A 10e-3 A
rangev
21 V
20 V
20 V
limiti
10e-3 A
10e-3 A
10e-3 A
limitv
1110 V
20 V
20 V
lorangei 1e-6 A 1e-8 A 1e-8 A
lorangev
0.21 V
0.20 V
0.20 V
Default measurement NPLC
0.01
0.01
0.01
Maximum NPLC
10
25
25
Minimum NPLC
0.01
0.001
0.001
CMTR settings after a devint command (defaults)
Item 4210-CVU
Measurement mode
System
Cable compensation
Off
AC V HI
HCUR/HPOT
DC V HI
HCUR/HPOT
AC drive level
0.045 V
Measurement model Cp, Gp
Measurement speed
FAST
Frequency
100 kHz
DC voltage offset
0.0 V
Sample hold time
0.0 s
DC presoak voltage
0.0 V
DC bias
0.0 V
DC sample count 1
Sample interval
0.0 s
Current range
1 mA
Also see
clrcon (on page 3-17)
clrscn (on page 3-17)
clrtrg (on page 3-19)
devclr (on page 3-26)
kibdefint (on page 3-37)
