3: LPTLib command reference S530/S540 KTE Linear Parametric Test Library (LPTLib) User's Manual
3-32 S530-900-01 Rev. E / September 2017
SMU parameter
Returns
Comment
KI_COMPLNC
Active compliance status for
fixed range
In range compliance if 1
KI_COMPLNC_EVER
Compliance history Reset by reading compliance history and by the
devint
command
KI_2600_ANALOG_FILTER
The active state of the analog
filter for a specified SMU
For 26xx SMUs; on or off
KI_SYSTEM_SPEED_MODE
The presently programmed
speed mode
FAST or LEGACY mode
KI_SETTLE_MODE
The presently programmed
settling mode
For 26xx SMUs:
SMOOTH = Additional settings options off
FAST_RANGE = Faster range changes
FAST_POLARITY = Polarity changes without
going to zero
DIRECT_IRANGE = SMU changes range
directly (default)
FAST_ALL
= All settle fast modes enabled
KI_CALDATE
The date the instrument was
last calibrated
Also see
None
imeast
This command forces a reading of the timer and returns the result.
Usage
int imeast(int instr_id, double *result);
instr_id
The instrument identification code of the device
result
The variable assigned to the measurement
Details
This command applies to all timers.
Also see
None
insbind
This command establishes a cooperative relationship between two instruments.
This command is valid only for CMTR2 on S540 systems with two CMTRs.
Usage
int insbind(int instr1, int instr2);
instr1
The first instrument to bind
instr2
The second instrument to bind
