3. Outer frame assembly
3.2 Outer frame assembly
3.2.6
After fitting the lateral outer frames, fit upper outer frame.
Insert corner connectors on one side first, then on the
opposite side.
To avoid damage, always use a
beating block - NEVER hit the outer
frame with the hammer!
3.2.7
Screw lateral outer frames with upper outer frames.
