Keller minimal windows 4+ - Inside Sealing of the Outer Frame; 8.1 EPDM Sealing Procedure

28
Keller minimal windows
®
Keller minimal windows
®
4+ 08
On-site installation | 997-000120 | 07-2021
8. Inside sealing of the outer frame
8.1
The inside EPDM sealing (500 mm or 700 mm available) is
to be carried out as follows - see red arrow & dashed line
Cleaning and dusting of building
surfaces.
EPDM foil must be be fixed with
contact adhesive.
