Keller minimal windows
®
Keller minimal windows
®
4+ 04
CLICK
26-00-012
max 50 mm
500 mm
On-site installation | 997-000120 | 07-2021
4. Sliding rail installation
Clip the sliding rail clamp
into the profile and push
the sliding rail in the
bottom outer frame.
Push the sliding rail clamp
with a flat screwdriver to
the bottom.
Beware, don‘t pusch to
hard because the clip can
break
After assembly, these clips
must clip nicely into the
outer frame.
4.2 freeway sliding rail
4.2
For the installation of slidings type „freeway“, the sliding
rail must be mounted according to the following procedure
and with clips 26-00-012.
