CELESTIAL 900 DOOR ADJUSTMENT
INFORMATION
1. OPEN THE DOOR AS FAR AS REQUIRED, AND
THE ADJUSTMENT ANGLE IS ACCESSIBLE.
2. MARK THE POSITION OF THE ADJUSTMENT
ANGLE ON THE FIREBOX. IT IS CRITICAL TO
PUT THE ADJUSTMENT ANGLE AT THE SAME
SPOT. SO THAT THE DOOR WILL LOCK
PROPERLY.
3. LOOSEN THE 2 BOLTS AS REQUIRED. DO NOT
UNSCREW THE BOLTS ALL THE WAY OUT.
4. PUSH THE PACKER FROM THE BOTTOM EDGE
OF THE ADJUSTMENT ANGLE UNTIL FULLY
REMOVED. ONLY TAKE OUT WHAT IS
NECESSARY. RE-POSITION THE ADJUSTMENT
ANGLE AT THE MARKERS AND TIGHTEN.
NOTE: UP TO 4 PACKERS CAN BE REMOVED IF
NECESSARY.
5. CLOSE THE DOOR AND CHECK IF THE LATCH
LOCKS PROPERLY, THE ADJUSTMENT IS
COMPLETE IF NO ADJUSTMENT IS NEEDED.
