Kemlan CELESTIAL 900 - HEARTH REQUIREMENTS FOR INSTALLATION ONTO A RAISED HEARTH

HEARTH REQUIREMENTS FOR
INSTALLATION ONTO A RAISED HEARTH
CELESTIAL 900
UNIT
X
Y
* NOTE: IF Y IS LESS THAN 200mm THEN REFER TO HEARTH MEASUREMENT ON PREVIOUS PAGE
X. MIN. DEPTH MEASUREMENT (mm) 300
Y. MIN. HEIGHT INCREASE (mm) 200*
20/08/2020 ver. 29 6
UNDERNEATH UNIT
AND HEARTH
THICKNESS MUST BE
A MINIMUM 18mm
NON COMBUSTIBLE
MATERIAL FC SHEET
OR SIMILAR
