KEMPOWER C Series - 3.3 S-Series AC Satellite Variants

Figure 2. Charging status.
Status LEDs on the charge post indicate different states : Green- Charger ready to be used
(1), Blue- Charging and state of charge (2), Red- Fault.
3.3 S-Series AC
Three types of S-Series AC Satellites are available:
2 x AC sockets.
CHAdeMO on the left-hand-side and AC socket on the right-hand-side.
AC socket on the left-hand-side and CCS2 on the right side.
C- AND S-OPERATION MANUAL - EN
7
11/11/2021 1.07
