Function panels
Pressure too low -signal lamp
Coolant overheating -signal lamp
Test switch
Torch cooling method selection
Switches and connectors
1 TIG HF ignition /current selection
22 TIG contact ignition/current selection
3 Post gas time adjustment 0…100 s.
4 Welding current downslope adj. 0…15 s.
5 Current adj. knob/parameter adjustment
6 Local-/remote control selection/code lock
12 Pregas time adjustment/code lock
13 Welding current upslope adjustment 0…5 s.
14 2T/4T-selection
19 Broken arc
21 MMA welding selection
Basic panel
