Kemppi MasterTig 1500 - Service Manual

31 pages

Save Page as PDF

To Next Page

Service manual

Ver. 1.0

1400

1500

2200

2800

3500

1500

2200

2800

3500

Main Page

Questions and Answers

M
Melissa DavisAug 6, 2025
Why do the net fuses blow during startup with my Kemppi MasterTig 1500 Welding System?
- L
  lgravesAug 6, 2025
  The net fuses might be blowing due to several reasons: * A faulty primary side power semiconductor. You should check the condition of the primary rectifier and IGBT-module. * A faulty main circuit card. Inspect the smoothing and load capacitors and look for any insulation damages on the main circuit card. * A faulty secondary unit. Check the condition of the secondary diodes.
M
Molly SpencerAug 20, 2025
What to do if the Kemppi Welding System power source will not start and MMA open circuit voltage is 0 V?
- A
  Amy HernandezAug 21, 2025
  If the power source of your Kemppi Welding System doesn't start and the MMA open circuit voltage is 0 V, consider the following checks: * Net fuses * Supply cable condition * Main switch condition * Potentiometer condition * Control method selection switch condition * Auxiliary transformer condition * Condition of the primary rectifier and the IGBT-module * Flat cable condition

Summary

General Information

Technical Data, Switches, and Connectors

Overview of technical specifications, switches, and connection points for welding machines.

Mastertig Control Panels (1500;2200)

Mastertig Control Panels (2800;3500)

Operation Principle and Electrical Analysis

IGBT Gate Pulse Analysis (2800;3500)

Shows IGBT gate pulse waveforms for 2800/3500 models at min/max power.

Lower IGBT Voltage Analysis (2800;3500)

Displays voltage over the lower IGBT for 2800/3500 models at min/max power.

Secondary Diode Voltage Analysis (2800;3500)

Presents voltage after secondary diodes for 2800/3500 models at min/max power.

IGBT Gate Pulse Analysis (1400;1500;2200)

Lower IGBT Voltage Analysis (1400;1500;2200)

Secondary Diode Voltage Analysis (1400;1500;2200)

Troubleshooting

Troubleshooting Diagram

Provides a guide for diagnosing and resolving common machine issues.

Control Card A001 Overview

Block Diagram and Functions

Mastertig TIG-section Functions

Programmatic Functions Overview
