Kemppi SA 35 Quick Start Guide

10 11
© Kemppi Oy 2020
SA 35, SA 60B, SA 60i, XA 47
2002
XA 47
DIN14-15
Weld
Cut
Grind
XA 47
4/9-13/14-15 KMP 1/1/1/2/379 ANSI KMP Z87 CSA KMP Z94.3 AS/NZS 1338.1
O
3
45
2
1
1. Battery holder (1 x CR2450).
2. Low battery indicator: Immediately replace the battery
when the indicator and display ashes.
3. Grind, Cut, Weld or DIN 14–15 selection.
When DIN14-15 mode is selected, the indicator lights
in front of both WELD and DIN14-15 light up.
4. Shade, Sensitivity or Delay selection.
5. Adjust Shade, Sensitivity or Delay values, +/-.
• Shade: WELD mode: 9-13
14-15 mode: 14-15
• Sensitivity: 1-5
• Delay: 1-5
DIN14-15
Weld
Cut
Grind
SHADE
SENSITIVITY
DELAY
XA 47
4/9
-13/14-15 KMP 1/1/1/2/379
ANS
I KMP Z87
CSA
KMP Z94.3 AS/NZS 1338.1
O
DIN14-15
Weld
Cut
Grind
SHADE
SENSITIVITY
DELAY
XA 47
4/9-13/14-15 KMP 1/1/1/2/379 ANSI KMP Z87 CSA KMP Z94.3 AS/NZS 1338.1
O
DIN14-15
Weld
Cut
Grind
SHADE
SENSITIVITY
DELAY
XA 47
4/9-13/14-15 KMP 1/1/1/2/379 ANSI KMP Z87 CSA KMP Z94.3 AS/NZS 1338.1
O
You can adjust the function values for the WELD mode
and DIN14-15 mode only. For the CUT and GRIND modes,
the values of sensitivity and delay remain the same as they
were in WELD mode, and the shade value changes to 4 for
GRIND and to 5 for CUT.
