PARTS LIST
4 1
45 1
CLIP, F/ GREASE CUP
7 1
8 1
9 1
10 1
11 1
Not Pictured
13 1
1
PRODUCT MANUAL, ENGLISH
14 1
1
PRODUCT MANUAL, SPANISH
15 1
16 1
17 2
18 2
19 1
20 1
21 1
22 3
23 1
24 2
25 1
26 1
27 1
28 1
29 4
30 4
31 1
32 1
33 1
Those on your particular grill model. However, the method of assembly remains the same.:
34 1
35 1
36 1
37 1
38 1
39 1
40
1
41 1
NOTE: Some grill parts shown in the assembly steps may differ slightly in appearance from:
Key Description Qty Part
Number
Key
69 Left Bottom Shelf 1 61300091 87 Smoker Door 1 61300078
70 Support Angel Bar 2 40900060
88 Gasket Strip 1 61300121
71 Lower Door Magnet Box 1 40200072
89 Grease Tray, Smoker 1 61300071
72 Right Bottom Shelf 1 61200116 90 Bracket, Wood Chip Pan 1 61300115
73 Caster with brake 2 40900212
91 Wood Chip Pan 1 61300073
74 Caster 2 40900213
92
Lid, Wood Chip Pan
1 61300074
75 Back Bottom Support Bar 1 61200125 93 Smoker Burner Bracket 1 61300069
76 Front Bottom Support Bar 1 61200127 94 Smoker Burner 1 61300113
77 Left Door, Main Cabinet 1 61200068
95 Cooking Grate Bracket,
Smoker
8 61300114
78 Door Handle 4 61200217 96 Cooking Grates, Smoker 3 61300116
79 Right Door, Main Cabinet 1
61200072
97 Smoker Box 1 61300034
80 Tool Bracket 1 61200107 98 Smoker Orifice Bracket 1 61300070
81 Right Cabinet Door 1 61200101 99 Back Panel, Smoker 1 61300072
82 Left Module Bracket 1 61300031 100 Hook 4 61200213
83 Insulate Plate, Left Module
Bracket
2 61300162 101 Push Bar 1 61200212
84 Left Panel, Left Cabinet 1 61300028
102 Fascia, Left Side Shelf 1 61300022
85 Hole Cap 2 61300087 103 Left Side Shelf 1 61300019
86 Temperature Gauge, Smoker 1 61300120
Not Pictured
Hardware Pack 1 61300101
Manual 1 61300100
