Kenmore 146.23766310 - Parts List

146.23766310
•
13
PARTS LIST
Key
Qty
Description
1 2
42 3
HEAT DIFFUSERS
2
1
43 3
COOKING GRATE
3 1
44 1
SWING AWAY GRATE
4 1
45 1
CLIP, F/ GREASE CUP
5 1
46 1
GREASE CUP
6
2
47 1
TANK THUMBSCREW
7 1
8 1
9 1
10 1
11 1
Not Pictured
12 1
1
HARDWARE PACK
13 1
1
PRODUCT MANUAL, ENGLISH
14 1
1
PRODUCT MANUAL, SPANISH
15 1
16 1
17 2
18 2
19 1
20 1
21 1
22 3
23 1
24 2
25 1
26 1
27 1
28 1
29 4
30 4
31 1
32 1
33 1
Those on your particular grill model. However, the method of assembly remains the same.:
34 1
35 1
36 1
37 1
38 1
39 1
40
1
41 1
NOTE: Some grill parts shown in the assembly steps may differ slightly in appearance from:
Key Description Qty Part
Number
Key
Description Qty
Part Number
1 Warming Rack 1 61200202 35 Cotter Pin 10 110050
2 Cooking Grate 3 61200203 36 Front Silicone Rubber Bumper 2 40700103
3 Heat Diffuser 6 40800023 37 Logo Plate 1 40800106
4 Grease Tray 1 61200022 38 Lid Handle Seat 2 40900013
5 Side Burner Grid 1 40800019 39 Lid Handle 1
61200011
6 Side Burner 1 40800121 40 Firebox Silicone Rubber Bumper 2 50300205
7 Side Burner Base 1 40800063 41 Firebox 1 61200004
8 Right Side Shelf 1 61200045 42 Grease Cup 1 40800026
9 Igniter Wire, Side(Smoker) Burner 2 61300105 43 Grease Cup Clip
1
40800131
10 Side Burner Lid 1 40200044 44 Main Burner 6 61200026
11 Rotate Axis, Side Burner Lid 1 61200216 45 Igniter Wire A 2 61200205
12 Fascia, Right Side Shelf 1 61200047 46 Igniter Wire B 4 61200206
13 Control Knob Bezel, Side Burner 1 61200051 47 Smoker Gas Line 1 61300098
14 Control Knob 7 40900206 48 Smoker Orifice 1 61300099
15 Side Shelf Bracket 2 61200056 49 Thermocouple 1 61300102
16 Folding Side Shelf 1 61200051 50 Smoker Burner Hose 1 61300097
17 Tank Heat Shield Bracket 1 61200025 51 Safety Valve, Smoker Burner 1 61300095
18
Tank Heat Shield
1
61200023
52 Manifold, Smoker Burner 1 61300017
19 Back Panel, Right Cabinet 1 61200091 53 Manifold, Main Burner 1 61200107
20 Match Holder Bracket 1 40800129 54 Gas Valve, Main Burner 6 61200024
21 Gas Hose Bracket 7 61300030 55 Regulator 1 40800115
22 Electronic Ignition Module 2 61200215 56 Side Burner Hose 1
61200214
23 Right Module Bracket 1 61300032 57 Gas Valve, Side Burner 1 61200213
24 Single Magnet Box 1 61200129 58 Control Panel 1 61300009
25 Magnet 3 40200094 59 Control Knob Bezel, Smoker
Burner
1 61300013
26 Match Holder 1 40800128 60 Control Knob Bezel, Main Burner 6 40900036
27 Right Panel, Main Cabinet 1 61200060 61 Control Knob, Smoker Burner 1 61300093
28 Right Panel, Right Cabinet 1 61200093 62 Back Rail 1 61200065
29 Right Cabinet Tank Baffle 1 61200098 63 Door Bracket, Main Cabinet 1 61200067
30 Door Bracket, Right Cabinet 1 61200100 64 Left Top Hinge Pin Bracket 1 40200056
31 Right Top Hinge Pin Bracket 2 40200057 65 Top Door Magnet 1 61300106
32 Temperature Gauge, Main Grill 1 61200201 66 Back Panel, Main Cabinet 1 61200062
33 Lid 1 61200004 67 Tank Baffle 1 40200070
34 Rotate Rod, Lid 2 50300207 68 Tank Holder 1 40800130
