Kenmore 146.23766310 - Page 17

146.23766310 • 17
BEFORE ASSEMBLY
Step 2: Open grill lid, take out the hardware pack from top of box, and take out the small boxes
packed within the grill head. Remove all packing materials, and remove all parts from boxes as
show in the figure below.
