9
Installation in a double-hung sash window
1. Cut a length of adhesive foam seal the
width of the window and attach it to the
window stool (see Fig. 8).
2. Place the window slider onto the adhesive
foam seal (see Fig. 9). Adjust window
slider width according to the instructions
on page 8.
3. Cut another length of adhesive foam seal
and attach it to the bottom of the window
sash. Close the window sash securely onto
the window slider (see Fig. 10).
4. Cut the non-adhesive thick foam seal to
window width and insert into the open
gap between the inner window and outer
window sash (see Fig. 11).
Fig.8
Fig.9
Fig.10
Fig.11
Adhesive Foam Seal
"Window Slider"
Window stool
26.57''-48.43''
"Window Slider"
"Window stool"
"Non-adhesive Thick Foam Seal"
