Kenmore 596.526732 - Installing Panels; Removing Panels

TOIHSTALLAHD
REMOVEPAFIELS
Toavoidpossibleinjury and damage
to property,tape decorativepanels
(somemodels)securely into place
whendoor handlesare removed.
To avoid personal injuryor
propertydamage,observethe
following: ....
> Refrigeratorpanelsshouldnot
weigh morethan30 pounds (14
kilograms)and freezerpanels
should notweighmore than 15
pounds(7 kil0grams),
> Protect soft vinyl or otherflooring
with cardboard,rugsor other
protectivematerial.
>- Protect hands and arms by
wearinggToves,
NOTE:
> To protectdoor surfacesfrom being
scratched,cover back edges of
decoratorpanels by placing masking
tapealong back edges
>- Save all screwsand reusein original
locations
1/2'(6 ram) PanelDimensions
Exte. ed
Door Panel Panel
Pane[ Height Width
Freshfood 66_/," 18'_/,_'
door (I69 5cm) (481 cm)
Upper t8 V_" 13'_/,_"
dispensing (46 cm) (35.4 crn)
freezerdoor
Lower 32_/3_" t3 '_/,_"
dispensing (815 cm) (35 4 cm)
freezerdoor
Non-' 66%" 13'_/,_"
dispensing (1695cm) (35 4 cm)
lreezerdoor
INSTALLING PANELS
t.. Removetoptrimscrewswitha
Phillipsscrewdriverand removetop
trim°
2_
4_
Slide handleupwarduntil _Jl "_
loose. Removehandle
from door
Removedoor
retainerclipswith
a 7,"hexhead
driver.
Slidebottom of panels intobottom
door trim until hingeside of decorator
panelrests under hingeside trim.
IMPORTANT:Tapetopsof panelsto 4.
doorto preventpane{sfrom fatiing
Reinstalldoor [_ _-_ 5
retainerclips with
a ¼"hexhead
driver.
Reinstallhandleby insertingretaining
clips on door intonotcheson backof
handle.
> Slidehandle down until it contacts
bottomtrim
7. Removetape from
tops of panels
beforereinstalling
topdoor trim with
Phillipsscrews
removedin step 1,
REMOVING PANELS
l Removetoptrimscrews witha
Phillipsscrewdriverand removetop
trim.
IMPORTANT:Tapetops of panelsto
door to prevent panels fromfalling.
Slide handte upwarduntil
loose. Remove handle
from door
Removedoor
retainerclips with
a ¼" hex head
driver.
Removetapeto slide panelsout of
door trim
Referto steps 5, 6 and 7 of
Installing Panels to instatl handles
andtrim.
