Why is my Kenmore 795.71026.010 Refrigerator Poor Defrosting?
Poor defrosting in your Kenmore Refrigerator can stem from several causes: a disconnected temperature fuse, a faulty heater, a jammed drain, or a poor relay for the heater. Unfortunately, further details on how to resolve these specific issues are not provided.
What to do if my Kenmore Refrigerator shows a Communication Error?
If your Kenmore Refrigerator shows a Communication Error, it's likely due to a poor connection in communication or a faulty TR (Transmitter and Receiver). Check the communication connection and the TR of the transmitter and receiver.
What causes Abnormality of Brushless DC FAN Motor for Freezer in Kenmore 795.71026.010?
If there's an Abnormality of Brushless DC FAN Motor for Freezer in your Kenmore Refrigerator, it typically occurs when the F/B signal doesn’t exceed 65 seconds during motor operation. Possible solutions include checking for a poor BLDC Motor connection, DRIVE IC, and TR.
What causes Abnormality of Brushless DC FAN Motor for Ice Making in Kenmore Refrigerator?
If there's an Abnormality of Brushless DC FAN Motor for Ice Making in your Kenmore Refrigerator, it typically occurs when the F/B signal doesn’t exceed 65 seconds during motor operation. Possible solutions include checking for a poor BLDC Motor connection, DRIVE IC, and TR.
What causes Abnormality of Brushless DC FAN Motor for Mechanic Room in Kenmore 795.71026.010?
If there's an Abnormality of Brushless DC FAN Motor for Mechanic Room in your Kenmore Refrigerator, it typically occurs when the F/B signal doesn’t exceed 65 seconds during motor operation. Possible solutions include checking for a poor BLDC Motor connection, DRIVE IC, and TR.
General| Brand | Kenmore |
|---|---|
| Model | 795.71026.010 |
| Category | Refrigerator |
| Language | English |
Crucial safety step to disconnect power before any service work.
Disclaimer regarding the intended audience and liability.
Detailed electrical ratings and consumption data for the unit.
Performance metrics under no-load conditions at different ambient temperatures.
Specifications related to the refrigeration system, including pressure and refrigerant.
Clearance requirements for proper installation and air circulation.
List of common replacement parts with their part numbers.
Diagram illustrating the air flow within the refrigerator compartments.
Identification of the refrigerator light component.
Identification of the internal water filter component.
Identification of modular bins located on the doors.
Identification of fixed bins on the refrigerator doors.
Identification of another fixed bin on the refrigerator doors.
Identification of the shelves within the refrigerator compartment.
Identification of the ice maker and ice bucket area.
Identification of the humidity-controlled crisper drawer.
Identification of the Glide'N'Serve feature.
Identification of an additional ice bin.
Identification of the pull-out drawer.
Identification of the Durabase component.
Identification of the divider component.
Identification of the dairy bin.
Identification of the water tank cover.
Detailed procedure for safely removing and reinstalling refrigerator doors.
Instructions for removing and replacing the door gasket.
Steps to adjust refrigerator doors for proper alignment and sealing.
Procedure for removing and replacing the evaporator fan and motor assembly.
Procedure for replacing the ice fan scroll assembly.
Steps to remove and replace the defrost control assembly and its components.
Instructions for replacing the refrigerator compartment lamp.
Procedure for removing and accessing the multi-duct component.
Instructions for changing the freezer compartment light.
Steps to remove and replace the main Printed Wiring Board (PWB).
Procedure for accessing and removing the dispenser unit.
Instructions on how to remove and replace the display Printed Wiring Board (PWB).
Steps to remove and replace the dispenser funnel.
Procedure for replacing the sub Printed Wiring Board (PWB) for the dispenser.
Steps for removing and replacing the duct door component.
Procedure to remove and replace the ice corner door.
Instructions for removing and replacing the icemaker assembly.
Steps to remove the cover for the auger motor.
Guide on how to safely remove the ice bin from the door.
Guide on how to properly insert the ice bin into the door.
Step-by-step guide for removing and reinstalling the pullout drawer.
Procedure for disassembling the water valve component.
Method for disassembling the fan and fan motor.
Instructions for separating and removing the pull-out drawer.
Information about the compressor's role and usage notes.
Overview of the E-Linear compressor, its design, and control.
Table detailing error codes, their causes, and recommended service actions.
Identification and labeling of the main PCB and its connectors.
Images of the display PCB and sub PCB, showing their part numbers.
Procedure for diagnosing and resolving the freezer sensor error.
Procedure for diagnosing and resolving the refrigerator sensor error.
Procedure for diagnosing and resolving the icing sensor error.
Procedure for diagnosing and resolving the defrost sensor error.
Procedure for diagnosing and resolving the defrost heater error.
Procedure for diagnosing and resolving the freezer fan error.
Procedure for diagnosing and resolving the icing fan error.
Procedure for diagnosing and resolving the condenser fan error.
Procedure for diagnosing and resolving communication errors.
Steps to troubleshoot when the cube mode is not functioning.
Steps to troubleshoot when the crush mode is not functioning.
Steps to troubleshoot when the water dispensing mode is not functioning.
Troubleshooting for the freezer compartment's AC bulb lamp.
Troubleshooting for the refrigerator compartment's lamp.
Steps to diagnose and fix poor cooling in the fresh food section.
Method for checking the damper and its PCB.
Procedure to check the fan motor's condition.
Procedure to check the voltage of the F Fan motor.
Steps to diagnose and fix poor cooling in the freezer compartment.
Steps to diagnose and fix over cooling in the fresh food compartment.
Guide on entering test mode and removing Terminal Position Assurance (TPA).
Procedure for removing Terminal Position Assurance (TPA).
Chart correlating temperature with resistance and voltage for freezer/icing sensors.
Chart correlating temperature with resistance and voltage for refrigerator/defrost sensors.
Procedure for checking and diagnosing fan errors.
Procedure to access the PCB for compressor troubleshooting.
Method to check LED blinking frequency on the PWB for diagnosis.
Testing methods for the defrost controller assembly, including fuse-M and sensor.
Procedure for testing the sheath heater used for defrosting.
Testing procedure for the door heater assembly.
Method for testing the refrigerator and freezer door switches.
Procedure for testing the dispenser DC motor.
Testing procedure for the ice auger motor assembly.
Testing procedure for the damper assembly.
Procedure for testing the light bulb socket.
Procedure for testing the flow sensor.
Details about the linear compressor, its label, and types.
Table of inverter error codes, their causes, and LED flash counts.
Procedure for checking the IPM voltage output during operation.
Procedure for checking compressor insulation resistance to ground.
A diagnostic chart to identify causes and remedies for refrigerator complaints.
Troubleshooting chart for refrigeration cycle issues like leakage and clogging.
Diagnostic flowchart for sealed system issues, including leaks and undercharge.
Step-by-step operational principle of the icemaker from power on to test mode.
Details on the different functions of the ice maker, including Icemaking, Harvest, and Fill/Park modes.
Procedure for performing forced operation tests on the ice maker.
Information on error codes displayed by the ice maker water supply control panel.
Overview of the refrigerator's basic functions and initial settings.
Instructions for switching the temperature display between Fahrenheit and Celsius.
Procedure for locking and unlocking the dispenser and control panel buttons.
Explanation of the water filter replacement indicator light.
Details on the Ultra Ice function for quick freezing.
Instructions on how to select water or ice from the dispenser.
Explanation of the dispenser light modes (Normal, Auto, On).
Information on the control of the freezer fan motor's speed settings.
Explanation of the cooling fan motor's operation in conjunction with the compressor.
Details on the control of the ice compartment fan.
Detailed explanation of the Ultra Ice function's purpose and operation.
Description of the door alarm feature and its behavior.
Instructions for entering and canceling the display mode.
Explanation of the defrosting cycle, its timing, and conditions.
Overview of the automatic diagnosis system for detecting defects.
Diagram and part numbers for valve and water tube components.
Detailed list of case part numbers and descriptions.
Continuation of the case parts list with part numbers.
Detailed list of door part numbers and descriptions.
