CARING FOR YOUR MICROWAVE OVEN
REPLACING THE COOKTOP
AND OVEN LIGHTS
REPLACING THE COOKTOP
AND OVEN LIGHTS
5. Slide a new charcoal filter into place. The filter
should rest at the angle shown.
6. Slide the bottom of the vent grille into place. Push
the top and slide right until it snaps into place.
Replace the
mounting screw.
7. Plug in microwave oven or reconnect power.
NOTE: Do not operate the hood without the grease
filters in place.
CARING FOR THE FILTERS
(CONT.)
The cooktop light
1. Unplug microwave oven or disconnect power.
2. Remove the bulb cover mounting screw.
3. Replace bulb with candelabra-base 30-watt bulb
(Part No. 6912W3Q001A) available from Sears by
calling 1-800-4-MY-HOME.
4. Plug in microwave oven or reconnect power.
The oven light
1. Unplug microwave oven or disconnect power.
2. Remove the vent grille mounting screw.
3. Slide the grille left and tip forward, then lift out to
remove.
REPLACING THE COOKTOP
AND OVEN LIGHTS
