16
HOW TO REMOVE THE FREEZER DRAWER
WARNING
: Use two or more people to remove and
install the freezer drawer. Failure to do so can result in
personal injury, product or property damage.
1.
Take out the ice bin first, and then take out the upper
freezer drawer by lifting it up.
2.
Remove lower freezer basket by pulling up and tilting
toward refrigerator until it can be removed from the
freezer drawer/door assembly.
3.
Push down on the rail locking tabs while pulling the
freezer drawer outwards to release the inner rail
tracks from the cabinet. With the aid of an assistant,
continue to pull the drawer outwards until the inner and
outer rail tracks are fully extended and the drawer is
completely removed from the cabinet.
4.
Pull exterior freezer drawer to fully disengage the rail
assembly from the unit. Use 2 people for this task as
the door is heavy and awkward to handle.
CAUTION
: Do not hold the handle when removing or
replacing the drawer. The handle may come off and it
could cause personal injury.
5.
Place the door on a non-scratch surface.
REFRIGERATOR INSTALLATION
Locking Tab
Kenmore향 31 큐빅(영+스)_F840-2(KLBH031A@E).indd 16 2021-03-23 오후 3:22:30
