Kenmore PG-40407S0LF-1 - Parts List

Key
Description
Qty
Part Number
Key
Description
Qty
Part Number
A1
Side Burner Lid
1
407F0100Z
B16
Drip Cup Clip
1
40800131
A2
Side Burner Grid
1
40800119
B17
Drip Cup
1
40800026
A3
Side Burner Base
1
40800063
B18
Middle Panel, Left and Right Cart
2
41600049Z
A4
Side Burner
1
40800121
B19
Bottom Panel, Left and Right Cart
2
407F0038Z
A5
Igniter Wire, Side Burner
1
40800120
B20
Door Magnet, Side Cabinet
2
61200128Z
A6
Side Shelf Handle
2
407P0001
B21
Left Side Door
1
407F10054
A7
Right Side Shelf
1
407P0002
B22
Left Door
1
407F10086
A8
Fascia, Right Side Shelf
1
407P0003
B23
Right Door
1
407F10095
A9
Electronic Ignition Module
1
407F10012
B24
Right Side Door
1
407F10049
A10
Control Panel
1
407F10080
B25
Door Handle
4
407F10076
A11
Bezel, Control Knob
5
407F10036
C1
Fascia, Left Side Shelf
1
407P0004
A12
Control Knob
5
407F10206
C2
Back Panel, Left and Right Cart
2
407P0005
A13
Gas Valve, Main Burner
4
40900205
C3
Middle Cart Top Back Rail
1
407P0006
A14
Gas Valve ,Side Burner
1
40900209
C4
Door Rail
1
40700085Z
A15
Manifold, Main Burner
1
40800037
C5
No.2 Middle Cart Bottom Back Rail Bracket
1
407P0013
A16
Side Burner Hose
1
40900210
C6
No.1 Middle Cart Bottom Front Rail Bracket
1
407P0014
A17
Cotter Pin
8
110050
C7
Back Panel
1
407P0007
A18
Regulator
1
40800115
C8
Door Magnet Box
1
407F0099Z
B1
Lid
1
407F10004
C9
Middle Cart Bottom Panel
1
407F0048Z
B2
Temperature Gauge
1
407F10201
C10
Gas Tank Holder
1
40800130Z
B3
Logo
1
407F10106
C11
No.1 Leg Frame
1
407P0008
B4
Rotate Rod, Lid
2
407P0012
C12
No.2 Leg Frame
1
407F0025Z
B5
Silicone Rubber Bumper
2
40700103
C13
No.3 Leg Frame
1
407F0021Z
B6
Bezel, Lid Handle
2
407F10013
C14
No.4 Leg Frame
1
407P0009
B7
Lid Handle
1
407F10012Z
C15
No.2 Left Cart Bottom Back Rail
1
407F0018Z
B8
Warming Rack
1
40900203
C16
No.1 Left Cart Bottom Front Rail
1
407F0015Z
B9
Cooking Grate
2
40900204
C17
Left Cart Top Front Rail
1
407P0010
B10
Heat Diffuser
4
40800023
C18
Right Cart Top Front Rail
1
407P0011
B11
Flame Carry Over Tube
3
40800022
C19
Tank Baffle
1
407F0075Z
B12
Main Burner
4
40700125
C20
No.3 Right Cart Bottom Front Rail
1
407F0034Z
B13
Firebox
1
40700021
C21
No.4 Right Cart Bottom Back Rail
1
41600042Z
B14
Igniter Wire, Main Burner
1
40900207
C22
Caster With Brake
2
407F10100
B15
Drip Tray
1
407F0074
C23
Caster
2
407F10101
12
Not Picture
Hardware Pack
1
407P0016
Manual
1
407P0015
PARTS LIST
If you are missing hardware or have damaged parts after
unpacking grill, call 1-888-287-0735, M-F 8:00 -5:00
PACIFIC for replacement.
To order replacement parts after using grill, call
1-888-287-0735.. M-F 8:00-5:00 PACIFIC..
NOTE: Some grill parts shown in the assembly steps may differ slightly in appearance from
those on your particular grill model. However, the method of assembly remains the same.
