Drip Tray and Drip Cup
□ Put Drip Tray in the middle of left and right Drip Tray Support as shown.(A)
□ Fit drip cup into drip cup clip. Hang drip cup clip at the bottom of drip tray.(B)
32
14
A
B
CAUTION
Failure to install drip cup clip and cup will
cause hot drip to drip from bottom of grill
with risk of fire or property damage.
