COMPACT Hi-Fi COMPONENT SYSTEM
RXD-M47WM-H/M47WM-S
LS-M47WM-H/M47WM-S
SERVICE MANUAL
(HM-437WM)
© 2005-9 PRINTED IN KOREA
B51-5961-00 (K/K) 592
In compliance with Federal Regulations, following are repro-
duction of labels on, or inside the product relating to laser
product safety.
KENWOOD Corp. certifies this equipment conforms to DHHS
Regulations No.21 CFR 1040. 10, Chapter 1, subchapter J.
DANGER : Laser radiation when open and interlock defeated.
AVOID DIRECT EXPOSURE TO BEAM.
Caution : No connection of ground line if disassemble
the unit. Please connect the ground line on
rear panel, PCBs, Chassis and some others.
CD cover ass’y *
(F07-)
Phone jack
(E63-1365-08)
Power knob
(K29-8499-08)
Display/Rec. knob
(K29-8501-08)
Search knob
(K29-8503-08)
Cass lid ass’y *
(A53-)
Front cabinet *
(A60-)
Volume knob
(K29-8502-08)
CD/Tuner/Tape knob
(K29-8504-08)
EQ/Bass knob
(K29-8500-08)
.
* Refer to parts list on page 26.

Kenwood HM-437WM Specifications

Amplifier Section

rate output power	5 W + 5 W
impedance	4 Ω

Tuner Section

FM tuning frequency range	87.5 MHz ~ 108 MHz
AM tuning frequency range	531 kHz ~ 1, 602 kHz

CD Player Section

laser wave length	760 ~ 800 nm
over sampling	8 fs (352.8 kHz)
D/A conversion	1 Bit

General

power consumption	25 W
dimensions	W : 145mm, H : 210 mm, D : 227 mm
weight	2.8 kg

Speakers

enclosure	Bass-reflex type
speaker configuration	Full range, 100 mm, cone type
maximum input level	10 W
dimensions	W : 130 mm, H : 208 mm, D : 161 mm
weight	1.2 kg
