Kenwood KRF-V8010D Service Manual

KRF-V7510D/V8010D/VR-208/209
5
DISASSEMBLY FOR REPAIR
1. Remove the 8 screws (1,2,3),
remove the rear panel.
2. Connect the GND of the rear panel
and the chassis, the GND of the
mounting hardware and the chassis
with 2 alligators clip (
4)
1
2
2
4
4
4
3
3
x2
x2
x3
(VR-257)
VR-208(K) COVER-2P( 98.4.24 16:32 y[W 10
