PARTS LIST
Indicates safety critical com po nents.
Ref. No.
A
d
d
N
e
w
Parts No. Description
Desti-
nation
Ref. No.
A
d
d
N
e
w
Parts No. Description
Desti-
nation
45
KVT-514/524DVD/534DVD
/534DVDM/54DVDR/554DVD
E1: KVT-524DVD (Europe) Q1: KVT-554DVD Q2: KVT-54DVDR (Russian)
K: KVT-514 (North America) X1: KVT-534DVD (Australia) R1: KVT-534DVD (Latin America)
M1: KVT-534DVD M2: KVT-534DVDM (Other Areas)
236 1C
✽
B07-3300-02 ESCUTCHEON Q1
236 1C
✽
B07-3301-02 ESCUTCHEON Q2
236 1C
✽
B07-3305-02 ESCUTCHEON
M1M2X1
237 3F B11-1453-04 REFLECTION SHEET
LCD1 2C
✽
B38-1203-05 LCD
238 2F D10-4836-13 ARM ASSY
239 2F D10-4837-34 LEVER ASSY
240 2E D10-4840-03 ARM
243 3F D13-2335-03 RACK (GEAR)
244 3F D13-2336-03 RACK (GEAR)
246 1F D13-2338-04 GEAR
247 1F D13-2339-04 GEAR
248 2F D13-2340-04 GEAR
249 1F D13-2341-04 GEAR
250 1F D13-2342-04 GEAR
251 1F D13-2343-04 GEAR
252 1E D13-2344-04 GEAR
253 2F D13-2345-04 GEAR
254 2F D13-2346-04 GEAR
256 1E D13-2349-04 GEAR
257 1E D13-2350-04 GEAR
258 1F D13-2351-04 GEAR
259 2F D13-2457-04 GEAR
260 2F D21-2446-13 EXTENSION SHAFT
FC3
2F2D
E39-0665-05 FLAT CABLE
274 2C F09-2950-04 SHEET
276 1D F09-2951-14 SHEET
277 2D F09-2952-04 SHEET
278 1D F09-2953-04 SHEET
279 1D F09-2954-04 SHEET
284 3C F12-0966-04 SHIELDING SHEET
290 3C F20-2447-03 INSULATING SHEET
292 2F G01-3222-04 COMPRESSION SPRING
293 3E G01-3223-14 TORSION COIL SPRING
294 3E G01-3224-04 TORSION COIL SPRING
295 2F G01-3225-04 EXTENSION SPRING
296 2F G01-3226-04 COMPRESSION SPRING
300 1F G01-4653-04 COMPRESSION SPRING
302 2E G11-3587-04 CUSHION
308 2E J19-7004-03 HOLDER
309 2F J19-7005-04 STABILIZER
310 2F J19-7007-03 HOLDER
314 3E J22-0198-32 MOUNTING HARDWARE ASSY
316 1E J22-0200-14 MOUNTING HARDWARE ASSY
318 1F J22-0202-14 MOUNTING HARDWARE ASSY
319 1F J22-0203-23 MOUNTING HARDWARE ASSY
320 1F J22-0206-33 MOUNTING HARDWARE ASSY
321 1F J22-0212-04 MOUNTING HARDWARE
325 3C J39-0864-14 SPACER
328 2F J90-1092-03 GUIDE
329 2E J90-1093-03 GUIDE
FPC1 2D J86-0052-05 FPC (LEAD FREE) (68P)
FPC2 2D J86-0038-15 FPC (LEAD FREE) (50P)
333 2C K24-4866-13 PUSH KNOB
338 2C K25-1925-12 PUSH KNOB
A 2E N09-6205-05 STEPPED SCREW
AA 1F N19-2327-04 FLAT WASHER
AB 1F N19-2328-04 FLAT WASHER
B 2F N09-6206-05 MACHINE SCREW (M2X2.2)
C 2E N09-6207-05 MACHINE SCREW (M2X3.5)
D 3F N09-6211-05 STEPPED SCREW
E 3F N09-6225-05 MACHINE SCREW
H 2E N09-6270-05 MACHINE SCREW (M1.7X2.2)
J 1D N09-6302-04 MACHINE SCREW
K 1D N09-6303-04 MACHINE SCREW
N 1F N19-2195-04 FLAT WASHER (1.6X4X0.25)
P 2F N19-2303-04 FLAT WASHER
Q 2E N29-0538-04 RETAINING RING (2)
T 3C N82-2005-48
BINDING HEAD TAPTITE SCREW
U 1D N82-2007-47
BINDING HEAD TAPTITE SCREW
344 2C S79-0858-05 SWITCH ASSY (7INCH)
PM1 1F T42-1097-04 MOTOR ASSY
PM2 1F T42-1099-04 MOTOR ASSY
347 2F W02-5121-05 ELECTRIC CIRCUIT MODULE
348 1F W02-5122-05 ELECTRIC CIRCUIT MODULE
F 3D N09-6227-15 MACHINE SCREW (M2.6X 3.2NI)
VME1 2C X92-6400-00
DVD MECHANISM ASSY (DVS-8220W)
D551-559 B30-1605-05 LED (2COLOR PG/RED)
D560 B30-1779-05 LED (1608_SR)
D561 B30-1605-05 LED (2COLOR PG/RED)
C1 CK73FB1C105K CHIP C 1.0UF K
C2 CK73HB1E103K CHIP C 0.010UF K
C3 ,4 CK73FB1C105K CHIP C 1.0UF K
C5 -7 CK73HB1E103K CHIP C 0.010UF K
C8 C90-5670-05 ELECTRO 2200UF 16WV
C9 CK73FB1A335K CHIP C 3.3UF K
C10 CK73FB1C105K CHIP C 1.0UF K
C11 C90-5670-05 ELECTRO 2200UF 16WV
C12 CK73GB1H104K CHIP C 0.10UF K
C13 CK73HB1E103K CHIP C 0.010UF K
C14 CK73FB1E474K CHIP C 0.47UF K
C15 CK73GB1H104K CHIP C 0.10UF K
C16 CK73EB1C106K CHIP C 10UF K
C18 CE32BQ1C221M CHIP EL 220UF 16WV
C19 CE32BF0J101M CHIP EL 100UF 6.3WV
C21 CK73FB0J475K CHIP C 4.7UF K
C22 CK73HB0J105K CHIP C 1.0UF K
C24 CK73GB1H104K CHIP C 0.10UF K
C25 CE32BQ1C101M CHIP EL 100UF 16WV
C26 CK73FB1E474K CHIP C 0.47UF K
C27 CK73GB1A105K CHIP C 1.0UF K
C28 CE32BQ1C101M CHIP EL 100UF 16WV
DVD PLAYER ASSY
VIDEO CONTROL UNIT (X15-127x-xx)
DISPLAY ASSY
