PARTS LIST
Indicates safety critical com po nents.
Ref. No.
A
d
d
N
e
w
Parts No. Description
Desti-
nation
Ref. No.
A
d
d
N
e
w
Parts No. Description
Desti-
nation
54
KVT-514/524DVD/534DVD
/534DVDM/54DVDR/554DVD
E1: KVT-524DVD (Europe) Q1: KVT-554DVD Q2: KVT-54DVDR (Russian)
K: KVT-514 (North America) X1: KVT-534DVD (Australia) R1: KVT-534DVD (Latin America)
M1: KVT-534DVD M2: KVT-534DVDM (Other Areas)
Q53 KRC408-P DIGITAL TRANSISTOR
Q54 ,55 HAT2218R-E DUAL FET
Q56 ,57 KRC408-P DIGITAL TRANSISTOR
Q58 ,59 HAT2218R-E DUAL FET
Q60 2SA1576A TRANSISTOR
Q61 2SC4617 TRANSISTOR
Q62 2SA1576A TRANSISTOR
Q63 2SC4617 TRANSISTOR
Q64 2SA1576A TRANSISTOR
Q65 2SC4617 TRANSISTOR
Q66 DTB123YK DIGITAL TRANSISTOR
Q67 DTC143EE DIGITAL TRANSISTOR
Q68 DTB123YK DIGITAL TRANSISTOR
Q69 DTC143EE DIGITAL TRANSISTOR
Q71 DTA124EE DIGITAL TRANSISTOR
Q72 DTC124EE DIGITAL TRANSISTOR
Q73 ,74 DTC144EE DIGITAL TRANSISTOR
Q75 KRA302-P DIGITAL TRANSISTOR
Q76 2SK3019 FET
Q77 KRA308-P DIGITAL TRANSISTOR
Q78 ,79 2SK3019 FET
Q80 DTA114EE DIGITAL TRANSISTOR
Q82 DTA124EE DIGITAL TRANSISTOR
Q350 2SC4081 TRANSISTOR
Q351 KRC410-P DIGITAL TRANSISTOR
Q352 DTA144EE DIGITAL TRANSISTOR
Q353,354 KRC410-P DIGITAL TRANSISTOR
Q355 DTA144EE DIGITAL TRANSISTOR
Q356,357 KRC410-P DIGITAL TRANSISTOR
Q358 DTA144EE DIGITAL TRANSISTOR
Q359 DTC124EE DIGITAL TRANSISTOR
Q360 KRC410-P DIGITAL TRANSISTOR
Q361 2SA1577 TRANSISTOR
Q362 DTC124EE DIGITAL TRANSISTOR
Q370 2SC4081 TRANSISTOR
Q371 DTA144EE DIGITAL TRANSISTOR
Q372,373 KRC410-P DIGITAL TRANSISTOR
Q451 2SA1576A TRANSISTOR
Q452 DTC144EE DIGITAL TRANSISTOR
E1Q1Q2
Q452 DTC144EE DIGITAL TRANSISTOR
M1M2X1
Q453 2SA1774 TRANSISTOR
Q454,455 DTC144EE DIGITAL TRANSISTOR
Q654 2SA1774 TRANSISTOR
Q655 2SC4617 TRANSISTOR
Q681 2SA1576A TRANSISTOR
TH351 PRF18BE471QS2 POSITIVE RESISTOR
A1 X86-4030-16 FRONT-END UNIT KR1X1
A1 X86-4032-72 FRONT-END UNIT
E1Q1Q2
A1 X86-4032-72 FRONT-END UNIT M1M2
D451-453 B30-3201-05 LED (RGB F3)
C1 ,2 CK73EB1E106K CHIP C 10UF K
C3 C93-1283-05 CHIP C 1.0UF K
C5 C93-1363-05 CHIP C 10PF
C6 C93-1464-05 CHIP C 0.012UF F
C7 CK73GB1H473K CHIP C 0.047UF K
C8 C93-1383-05 CHIP C 220PF F
C9 CK73GB0J225K CHIP C 2.2UF K
C11 CK73GB0J225K CHIP C 2.2UF K
C12 CK73HB1E103K CHIP C 0.010UF K
C13 CK73GB1A474K CHIP C 0.47UF K
C14 CK73HB1E103K CHIP C 0.010UF K
C15 CK73GB1H473K CHIP C 0.047UF K
C16 CK73HB1C183K CHIP C 0.018UF K
C17 CK73HB1E103K CHIP C 0.010UF K
C18 C93-1283-05 CHIP C 1.0UF K
C21 CK73GB0J225K CHIP C 2.2UF K
C22 CK73HB1H152K CHIP C 1500PF K
C23 CK73EB1E106K CHIP C 10UF K
C24 CK73GB1H103K CHIP C 0.010UF K
C25 C93-1460-05 CHIP C 2200PF F
C28 C93-1283-05 CHIP C 1.0UF K
C100 CC73GCH1H151J CHIP C 150PF J
C101 CK73GB1C104K CHIP C 0.10UF K
C102 CK73FB0J106K CHIP C 10UF K
C103 CK73GB1H103K CHIP C 0.010UF K
C104 CK73FB1C106K CHIP C 10UF K
C105 CK73GB1C104K CHIP C 0.10UF K
C106 CK73EB1A106K CHIP C 10UF K
C107 CK73EB1C106K CHIP C 10UF K
C108 CK73GB1C104K CHIP C 0.10UF K
C109 CK73FB1C105K CHIP C 1.0UF K
C110 CK73GB1H103K CHIP C 0.010UF K
C112 CK73FB1E154K CHIP C 0.15UF K
C113 CK73EB1E225K CHIP C 2.2UF K
C114 CK73GB1C224K CHIP C 0.22UF K
C115 CK73GB1C104K CHIP C 0.10UF K
C116 CK73EB0J226K CHIP C 22UF K
C117 CK73HB1H102K CHIP C 1000PF K
C118 CK73GB1H103K CHIP C 0.010UF K
C119 CK73HB1E103K CHIP C 0.010UF K
C120 CK73GB1C104K CHIP C 0.10UF K
C121 CK73HB1E103K CHIP C 0.010UF K
C122 CK73HB1A104K CHIP C 0.10UF K
C129 CK73EB1C106K CHIP C 10UF K
C130 CK73GB1H103K CHIP C 0.010UF K
C131 CK73EB1E106K CHIP C 10UF K
C132 CK73GB1H104K CHIP C 0.10UF K
C133 CK73GB1H103K CHIP C 0.010UF K
C134 CK73FB0J106K CHIP C 10UF K
C135 CK73GB1H103K CHIP C 0.010UF K
C140 CC73GCH1H151J CHIP C 150PF J
C145 CK73EB1C106K CHIP C 10UF K
C150,151 CK73FB1C106K CHIP C 10UF K
C200 CK73EB1A106K CHIP C 10UF K
C202 CK73EB1C106K CHIP C 10UF K
C203 CK73HB1E103K CHIP C 0.010UF K
C204 CC73HCH1H560J CHIP C 56PF J
VIDEO CONTROL UNIT (X15-127x-xx)
VIDEO UNIT (X35-4960-10)
To Next Page
