Kenwood NX-5200 F3 User Manual

3-14(No.RA018<Rev.002>)
CP600 RK74HB1J100J NET RESISTOR 10 Ω 1/16W J
CP601 RK74HB1J100J NET RESISTOR 10 Ω 1/16W J
CP700 RK74HB1J100J NET RESISTOR 10 Ω 1/16W J
CP701 RK74HB1J101J NET RESISTOR 100 Ω 1/16W J
CP702 RK74HB1J101J NET RESISTOR 100 Ω 1/16W J
CP850 RK74HB1J100J NET RESISTOR 10
Ω 1/16W J
CP851 RK74HB1J100J NET RESISTOR 10
Ω 1/16W J
CP900 RK74HB1J100J NET RESISTOR 10 Ω 1/16W J
CP901 RK74HB1J101J NET RESISTOR 100 Ω 1/16W J
CP903 RK74HB1J101J NET RESISTOR 100 Ω 1/16W J
CP904 RK74HB1J101J NET RESISTOR 100 Ω 1/16W J
CP905 RK74HB1J100J NET RESISTOR 10 Ω 1/16W J
CP906 RK74HB1J100J NET RESISTOR 10 Ω 1/16W J
CP907 RK74HA1J100J NET RESISTOR 10 Ω 1/16W J
CP908 RK74HB1J100J NET RESISTOR 10 Ω 1/16W J
CP909 RK74HB1J104J NET RESISTOR 100k Ω 1/16W J
CP910 RK74HB1J101J NET RESISTOR 100 Ω 1/16W J
CP911 RK74HB1J221J NET RESISTOR 220 Ω 1/16W J
CP912 RK74HB1J221J NET RESISTOR 220 Ω 1/16W J
CP913 RK74HB1J221J NET RESISTOR 220 Ω 1/16W J
CP914 RK74HB1J221J NET RESISTOR 220
Ω 1/16W J
CP915 RK74HB1J221J NET RESISTOR 220
Ω 1/16W J
E1 F10-3224-15 SHIELDING CASE
E2 F10-3228-05 SHIELDING CASE F2,F3,K2,K3
E2 F10-3228-15 SHIELDING CASE E,E2
E3 F10-3244-05 SHIELDING CASE F2,F3,K2,K3
E3 F10-3244-15 SHIELDING CASE E,E2
E4 F10-3236-05 SHIELDING CASE
E5 F10-3246-15 SHIELDING CASE
F1 FZA10BQ-3R15 FUSE (CC)
F2 F53-0498-05 FUSE
J1 E68-0426-05 JACK OTHERS
OT1 F10-3223-05 SHIELDING COVER
OT2 F10-3227-05 SHIELDING COVER
OT3 F10-3243-15 SHIELDING COVER
OT4 F10-3245-15 SHIELDING COVER
OT5 H52-1258-02 ITEM CARTON F2,F3,K2,K3
OT5 H52-2343-04 ITEM CARTON E,E2
S1 S70-0530-05 TACTILE PUSH SW
S2 S68-0931-05 PUSH SWITCH
TH400 ERTJ0V104H N THERMISTOR
TH700 ERTJ0V104H N THERMISTOR
X700 L77-3123-05 TCXO
X701 L77-1802-05 QUARTZ CRYSTAL
X850 L77-3121-05 QUARTZ CRYSTAL
XF670 L7B-0003-00 MCF
 Symbol No. Part No. Part Name Description Local

Kenwood NX-5200 F3 Specifications

General

Frequency Range	136-174 MHz
Number of Channels	1024
Waterproof Rating	IP67
Operating Temperature	-30°C to +60°C
Digital Mode	NXDN, DMR
Analog Mode	FM
Channel Spacing	25 kHz
Power Output	5W
RF Output Power	5W
Digital Protocol	NXDN
Modulation	16K0F3E
Operating Voltage	7.5 V DC
