Kenwood NX-5200 F3 User Manual

1-54 (No.RA018<Rev.002>)
16. MSK
Devia-
tion *3
[Analog
Wide]
1) Adj item:
[Aw MSK]
Adjust:[****]
Deviation meter
LPF: 15kHz
HPF: OFF
2) Adj item:
[Low1]→
[Low3]→
[Center2]→
[High1]→
[High3]
Adjust:[****]
PTT : ON
Press [ ] key to
store the adjust-
ment value.
1) Adj item:
[MSK Deviation
(Analog Wide)]
Deviation meter
LPF: 15kHz
HPF: OFF
2) Adj item:
[Low1]→
[Low3]→
[Center2]→
[High1]→
[High3]
Press [Transmit]
button.
Press [Apply All]
button to store the
adjustment value.
Devia-
tion
meter
Oscil-
lo-
scope
Panel ANT Panel [Panel
tuning
mode]
[],
[]
[PC
test
mode]
[←],
[→]
Write the value as fol-
lowings. 513 (Reference
value)
3.00kHz±0.05
kHz
[Analog
Narrow]
1) Adj item:
[An MSK]
Adjust:[****]
Deviation meter
LPF: 15kHz
HPF: OFF
2) Adj item:
[Low1]→
[Low3]→
[Center2]→
[High1]→
[High3]
Adjust:[****]
PTT : ON
Press [ ] key to
store the adjust-
ment value.
1) Adj item:
[MSK Deviation
(Analog Narrow)]
Deviation meter
LPF: 15kHz
HPF: OFF
2) Adj item:
[Low1]→
[Low3]→
[Center2]→
[High1]
→
[High3]
Press [Transmit]
button.
Press [Apply All]
button to store the
adjustment value.
Devia-
tion
meter
Oscil-
lo-
scope
Panel ANT Panel [Panel
tuning
mode]
[],
[]
[PC
test
mode]
[←],
[→]
Write the value as fol-
lowings. 513 (Reference
value)
1.50kHz±0.05
kHz
17.
CWID
Devia-
tion *3
[Analog
Narrow]
1) Adj item:
[An CWID]
Adjust:[****]
Deviation meter
LPF: 15kHz
HPF: OFF
2) Adj item:
[Low1]→
[Low3]→
[Center2]→
[High1]→
[High3]
Adjust:[****]
PTT : ON
Press [ ] key to
store the adjust-
ment value.
1) Adj item:
[CWID Deviation
(Analog Narrow)]
Deviation meter
LPF: 15kHz
HPF: OFF
2) Adj item:
[Low1]→
[Low3]→
[Center2]→
[High1]→
[High3]
Press [Transmit]
button.
Press [Apply All]
button to store the
adjustment value.
Devia-
tion
meter
Oscil-
lo-
scope
Panel ANT Panel [Panel
tuning
mode]
[],
[]
[PC
test
mode]
[←],
[→]
Write the value as fol-
lowings. 513 (Reference
value)
1.00kHz±0.10
kHz
*3: Refer to the “4.9.1 Necessary Deviation adjustment item for each signaling and mode” table.
Item Condition Measurement Adjustment Specifica-
tions
/Remarks
Panel tuning
mode
PC test mode Test-
equip-
ment
Unit Ter-
minal
Unit Parts Method

Kenwood NX-5200 F3 Specifications

General

Frequency Range	136-174 MHz
Number of Channels	1024
Waterproof Rating	IP67
Operating Temperature	-30°C to +60°C
Digital Mode	NXDN, DMR
Analog Mode	FM
Channel Spacing	25 kHz
Power Output	5W
RF Output Power	5W
Digital Protocol	NXDN
Modulation	16K0F3E
Operating Voltage	7.5 V DC
