1-6 (No.RA018<Rev.002>)

Analogue measurements made per EN standards or TIA/EIA 603 and specifications shown are typical.

P25 Digital measurements made per TIA 102CAAA and specifications shown are typical.

JVC KENWOOD Corporation reserves the right to change specifications without prior notice or obligation.

TRANSMITTER

RF Power Output 6W to 1W

Spurious Emission -36dBm ≤ 1GHz, -30dBm > 1GHz

FM Hum & Noise Analogue @ 25 kHz 45dB

Analogue @ 20 kHz 45dB

Analogue @ 12.5 kHz 40dB

Modulation Distortion Less than 2%

Modulation 16K0F3E, 14K0F3E, 14K0F2D, 12K0F2D, 11K0F3E,

8K50F3E, 7K50F2D, 8K30F1E, 8K30F1D, 8K30F7W,

8K10F1E, 8K10F1D, 8K10F1W, 4K00F1E, 4K00F1D,

4K00F7W, 4K00F2D
