PRODUCT SPECIFICATIONS
Alcohol Electric Cooktop
Two Burner Units
B61148 - 120V AC - two 8” (200mm) @ 2200 watts
B61149 - 240V AC - two 8” (200mm) @ 2200 watts
Overall dimensions: 22 1/2” x 13 1/2” x 5 3/4”
571.5mm x 342.9mm x 146mm
Cutout dimensions: 21 3/4” x 12 3/4” with 3” radius
552.5mm x 323.9mm with 76.2mm radius
Single Burner Units
B61144 - 120V AC - one 8” (200mm) @ 1100 watts
B61145 - 240V AC - one 8” (200mm) @ 1100 watts
Overall dimensions: 12 3/4” x 12 3/4” x 5 3/4”
323.9mm x 323.9mm x 146mm
Cutout dimensions: 12 1/4” x 12 1/4” with 3” radius
311.2mm x 311.2mm with 76.2mm radius
12 3/4"
21 3/4"
3" Radius required
13 1/2"
22 1/2"
5 3/4"
B61148 & B61149
12 1/4"12 1/4"
3" Radius required
12 3/4"
12 3/4"
5 3/4"
B61144 & B61145
