Installation
UNIT
TYPE
MAX CONNECTED
LOAD
POWER SUPPLY
INPUT
PLUG
TYPE
Electric Grill 3000 Watts 240V AC 13A 50/60Hz
3 wire cord no plug
Induction Cooktop 1800 Watts 240V AC 8A 50/60Hz 3 wire cord no plug
ELECTRICAL SUPPLY REQUIREMENTS
The supply for each wire cord must be from an individual grounded circuit that is
protected by a circuit breaker and rated per the specications shown in the table below:
IMPORTANT!
The supply for each wire cord must be
on independent circuits.
IMPORTANT!
If the electrical supply does not meet
the product specifications, consult
with a licensed electrician before
proceeding with installation!
22
Countertop Preparation
3
Your Combi System is supplied with a factory
installed polished stainless steel ange that
accepts nine oval head wood screws for
mounting. The trim ange of this unit is designed
to hold the unit rmly in place in the countertop.
If desired, you may seal the edge of the
countertop beneath the trim ange. We
recommend a NON-ADHESIVE such as
plumbers putty. This will help reduce the chance
of damage to the trim ange should the unit
need to be removed from the countertop. Should
you need to remove the unit from the countertop
after installation simply take a piece of shing
line and run back and forth under the trim ange
to break the caulk bond.
WARNING!
Allow a 2 inch (2”) minimum clearance
between the bottom of the unit and
combustible surface located below, ie:
the upper edge of a drawer installed
below the unit (see page 25). Failure
to provide proper clearances and
ventilation may result in a fire hazard.
