Kenyon Mediterranean - Product Specifications

Mediterranean Series Cooktop
PRODUCT SPECIFICATIONS
Two Burner
B41510 - 120V AC - one 6 1/2” (165mm) burner @ 1200 watts
one 8” (200mm) burner @ 1400 watts
B41511 - 240V AC - one 6 1/2” (165mm) burner @ 1200 watts
one 8” (200mm) burner @ 1800 watts
B41591 - 208V AC - one 6 1/2” (165mm) burner @1200 watts
one 8” (200mm) burner @ 1800 watts
Overall dimensions: 23-1/4” x 14-1/4” x 2-5/8”
590.6mm x 362.0mm x 66.7mm
Cutout dimensions: 21-3/4” x 12-3/4” with 1/4” radius
552.5mm x 323.9mm with 6.4 radius
Trimline
B41515 - 120V AC - two 6 1/2” (165mm) burners @ 1200 watts each
B41516 - 240V AC - two 6 1/2” (165mm) burners @ 1200 watts each
B41596 - 208V AC - two 6 1/2” (165mm) burners @ 1200 watts each
Overall dimensions: 21” x 12” x 2-5/8”
533.4mm x 304.8mm x 66.7mm
Cutout dimensions: 20” x 10-3/4” with 1/4” radius
508mm x 273mm with 6.4 radius
Single Burner
B41517 - 120V AC - one 6 1/2” (165mm) burner @ 1200 watts
B41518 - 240V AC - one 6 1/2” (165mm) burner @ 1200 watts
B41598 - 208V AC - one 6 1/2” (165mm) burner @ 1200 watts
Overall dimensions: 12” x 12-1/2” x 2-5/8”
304.8mm x 317.5mm x 66.7mm
Cutout dimensions: 10-3/4” x 11-1/2” with 1/4” radius
273.0mm x 292.1mm with 6.4 radius
Caribbean Series Cooktop
PRODUCT SPECIFICATIONS
Two Burner
B41601 - 120V AC - two 6 1/2” (165mm) burners @ 1200 watts each
B41602 - 240V AC - two 6 1/2” (165mm) burners @ 1200 watts each
B41692 - 208V AC - two 6 1/2” (165mm) burners @ 1200 watts each
Overall dimensions: 21” x 12” x 2-5/8”
533.4mm x 304.8mm x 66.7mm
Cutout dimensions: 20” x 10-3/4” with 1/4” radius
508mm x 273mm with 6.4 radius
Single Burner
B41605 - 120V AC - one 6 1/2” (165mm) burner @ 1200 watts
B41606 - 240V AC - one 6 1/2” (165mm) burner @ 1200 watts
B41696 - 208V AC - one 6 1/2” (165mm) burner @ 1200 watts
Overall dimensions: 12” x 12-1/2” x 2-5/8”
304.8mm x 317.5mm x 66.7mm
Cutout dimensions: 10-3/4” x 11-1/2” with 1/4” radius
273.0mm x 292.1mm with 6.4 radius
