Kenyon Mediterranean - Page 6

Alpine Series Cooktop
PRODUCT SPECIFICATIONS
Two Burner - Large
B49510 - 120V AC - one 6 1/2” (165mm) burner @ 1200 watts
one 8” (200mm) burner @ 1400 watts
B49511 - 240V AC - one 6 1/2” (165mm) burner @ 1200 watts
one 8” (200mm) burner @ 1800 watts
B49591 - 208V AC - one 6 1/2” (165mm) burner @ 1200 watts
one 8” (200mm) burner @ 1800 watts
Overall dimensions: 23-1/4” x 14-1/4” x 2-5/8”
590.6mm x 362.0mm x 66.7mm
Cutout dimensions: 21-3/4” x 12-3/4” with 1/4” radius
552.5mm x 323.9mm with 6.4 radius
Two Burner - Small
B49515 - 120V AC - two 6 1/2” (165mm) burners @ 1200 watts each
B49516 - 240V AC - two 6 1/2” (165mm) burners @ 1200 watts each
B49596 - 208V AC - two 6 1/2” (165mm) burners @ 1200 watts each
Overall dimensions: 21” x 12” x 2-5/8”
533.4mm x 304.8mm x 66.7mm
Cutout dimensions: 20” x 10-3/4” with 1/4” radius
508mm x 273mm with 6.4 radius
Single Burner
B49517 - 120V AC - one 6 1/2” (165mm) burner @ 1200 watts
B49518 - 240V AC - one 6 1/2” (165mm) burner @ 1200 watts
B49598 - 208V AC - one 6 1/2” (165mm) burner @ 1200 watts
Overall dimensions: 12” x 12-1/2” x 2-5/8”
304.8mm x 317.5mm x 66.7mm
Cutout dimensions: 10-3/4” x 11-1/2” with 1/4” radius
273.0mm x 292.1mm with 6.4 radius
