Scale back and bottom
1. Scale plate
2. RS-232C interface
3. Leveling screw foot
4. Power supply socket
5. Housing screws
(in models with 4
leveling screw feet,
first screw out both rear
ones)
6. Equipment for the
under-scales weighing
hanger
7. Transport protection
(solely models with an
internal adjustment
weight)
2
3
1
4
5
6
5
7
