CHAPTER 3. USE
Thehoodisdesignedtobeusedeitherforexhaustingorfilterversion.
Themodelswithnosuctionmotoronlyoperateinductingmode,andmust
beconnectedtoanexternalsuctiondevice(notsupplied).
Theconnectinginstructionsaresuppliedwiththeperipheralsuctionunit.
DUCTING VERSION
In this case the fumes are conveyed outside of the building by means
of aspecial pipe connected with the connection ring located on top of the
hood.
Attention!Theexhaustingpipeisnotsuppliedandmustbepurchasedapart.
Diameteroftheexhaustingpipemustbeequaltothatoftheconnectionring.
Inthehorizontalrunstheexhaustingpipemustbeslightlyslanted(about10°)
anddirectedupwardstoventtheaireasilyfromtheroomtotheoutside.
Attention! If the hood is supplied with active charcoal filter, then it must
beremoved.
Connectthehoodanddischargeholesonthewallswithadiameterequivalent
totheairoutlet(connectionflange).
Usingthetubesanddischargeholesonwallswithsmallerdimensionswill
causeadiminutionofthesuctionperformanceandadrasticincreaseinnoise.
Anyresponsibilityinthematteristhereforedeclined.
