Theinstallationcomesundertheexclusiveresponsibilityofspecialists.

Theinstallerisheldtorespectthelegislationandthestandardsenforceinhishomecountry

HOW TO STICK THE GASKET

Thegasketsuppliedwiththehobavoidsallinfiltrationofliquidsinthecabinet.

Hisinstallationhastobedonecarefully,inconformityofthefollowingdrawing.

Stickthegasket(2)twomillimetresfromtheexternal

edgeoftheglass,afterremovingtheprotectionsheet

(3).

FITTING – INSTALLING:

Thecut-outsizesare:

• Ensurethatthereisadistanceof50mmbetweenthehobandthewallorsides.

• Thehobsareclassifiedas“Y”classforheatprotection.Ideallythehobshouldbeinstalledwithplenty

ofspaceoneitherside.Theremaybeawallattherearandtallunitsorawallatoneside.On the other

side, however, no unit or divider must stand higher than the hob.

• Thepieceoffurnitureorthesupportinwhichthehobistobefitted,aswellastheedgesoffurniture,

thelaminatecoatingsandtheglueusedtofixthem,mustbeabletoresisttemperaturesofupto100°C.

• Donotinstallthehobatthetopofanonventilatedovenoradishwasher.

• Ensureunder the bottom of the hob casing a space of 20 mmtoensuregoodaircirculationofthe

electronicdevice.

• Ifadrawerisplacedunderthehob,avoidputtingintothisdrawerflammableobjects(forexample:

sprays)ornonheat-resistantobjects.

• Materialswhichareoftenusedtomakeworktopsexpandoncontactwithwater.Toprotectthecut-

outedge,applyacoatofvarnishorspecialsealant.Particularcaremustbetakenwhenapplyingthe

adhesivejointsuppliedwiththehobtopreventanyleakageintothesupportingfurniture.Thisgasket

ensuresagoodsealwhenusedinconjunctionwithsmoothworktopsurfaces.

• The safety gap between the hob and the cooker hood placed above must comply with the

recommendationsofthehoodmanufacturer.In thecaseof noinstructions,a distanceof760mm

minimumshouldapply.

• Theconnectioncordshouldnotbesubjectedtoanymechanicalconstraint.

WARNING:

Useonlyhobguardsdesignedbythemanufacturerofthecookingapplianceorindicatedbythemanufacturer

oftheapplianceintheinstructionsforuseassuitableorhobguardsincorporatedintheappliance.Theuseof

inappropriateguardscancauseaccidents.

CHAPTER 8. INSTALLATION INSTRUCTIONS

THE CUT-OUT SIZES ARE

TYP

WIDTH DEPTH

KIH 43-3B

420mm 490mm
