Kestrel Elite - CREATING GUN & BULLET PROFILES; CREATING TARGETS

25
24
Additional Ballistics data available on Elite Model only:
vCor – Vertical Coriolis Correction is the amount of the
elevation solution attributed to the Coriolis eect.
hCor – Horizontal Coriolis Correction is the amount of the
windage solution attributed to the Coriolis eect.
SpnD – Spin Drift is the amount of the windage solution
attributed to the spin drift.
AerJ - Aerodynamic Jump is the amount of the elevation
solution attributed to aerodynamic jump.
ToF – Time Of Flight is the time required for a bullet to reach
its target at a given range.
MaxO – Max Ordinate is the maximum height above the axis
of the barrel that a bullet will reach.
Drop – Drop is the total drop the bullet experiences.
Rsub – Subsonic Range is the distance traveled by the bullet
at which it slows to subsonic speed (<Mach 1).
BALLISTICS/RANGE CARD MENU CONT’D
Press only the sides of the impeller when removing and inserting
to avoid damaging the precision hub bearing. [
Figure 1] .
» Press FIRMLY on the impeller module to remove it.
» Insert the new impeller so the side that has the
small triangle (close to the perimeter) faces the
front of the Kestrel when installed.
Figure 1
IMPELLER REPLACEMENT
» Orient one “arm” of the module straight up .
[
Figure 2]. The impeller can be pushed in from
either side.
Figure 2
