10 11
Specifications
Technical:
› Input (Each): 1 HDMI Connector, Type A, 19 Pin Female
› Output (Each): 1 HDMI Connector, Type A, 19 Pin Female; 6-Pin Terminal Block for Analog L/R
Output; RCA Jack for Digital Audio Output [follows SPDIF format (IEC 60958 )]
› Bandwidth: TMDS bandwidth 10.2 Gb/s
› Link: Single Link
› DDC Signal (Data): Input DDC Signal - 5 Volts p-p (TTL)
› HDMI Video/Audio Signal: Input Video Signal - 1.2 Volts p-p
› DDC Communication: EDID and HDCP buffering between source and display
› Wired IR: modulated IR signal input, 0-5V TTL or -10to +10V, 3.5mm mono female connector with
signal on tip
› Power: External Power Supply – (KD-4x4CSA) 12V/2A, (KD-8x8CSA) 12V/5A
General:
› Regulation: CE, RoHS, WEEE
› Rack Mount:
1U, Full Rack Width (rack ears included)
› Enclosure: Black Metal
› Product Dimensions:
17.25” x 7.5” x 1.75”
› Shipping Dimensions:
21.25” x 13” x 3.5”
› Product Weight:
6.5 lb.
› Shipping Weight:
8 lb.
Important Product Warnings:
1. Connect all cables before providing power to the unit.
2. Test for proper operation before securing unit behind walls or in hard to access spaces.
3. If installing the unit into wall or mounting bracket into sheet-rock, provide proper screw support
with bolts or sheet-rock anchors.
Safety Instructions:
Please be sure to follow these instructions for safe operation of your unit.
1. Read and follow all instructions.
2. Heed all warnings.
3. Do not use this device near water.
4. Clean only with dry cloth.
5. Install in accordance with the manufacturer’s instructions.
6. Do not install near any heat sources such as radiators, heat registers, stoves, or other
apparatus (including amplifiers) that produce heat.
7. Only use attachments/accessories specified by the manufacturer.
8. Refer all servicing to qualified service personnel. Servicing is required when the device has
been damaged in any way including:
» Damage to the power supply or power plug
» Exposure to rain or moisture
Power Supply Use:
You MUST use the Power Supply provided with your unit or you VOID the
Key Digital
®
Warranty and risk damage to your unit and associated equipment.
KD-4x4_8x8CSA_Manual.indd 10-11 8/4/16 10:30 AM
