Key Digital KD-Pro4x1X - IR Remote Control; TCP;IP & RS-232 Commands

15
IR Remote Control
Model: KDRMSWPROK (uses CR2025 battery)
Please note that some remote buttons may have no functionality
Discreet
Input Select
Incremental
Input Select
Reserved
Auto Sensing
Enable
Device Select
(Used for
addressing
mode)
Auto Sensing
See Auto Sensing section of Connections, LEDs, Buttons, Slide Switches, Rotaries section for more
information.
TCP/IP & RS-232 Commands
KD-Pro2x1X/KD-Pro4x1X allows control over serial interface for bi-directional communication.
Use pins 4, 5, and 6 for RS-232 communication
Serial interface may also be accessed using a TCP/IP connection
› Default IP address is 192.168.1.239, with default port 23
