Keyde TFT850C - Product Name; Electrical Parameters

Zhejiang Chaoji Electric Tech.Co.,Ltd
浙江超级电气科技有限公司
Zhejiang Chaoji Electric Technology Co.,Ltd
1． Product Name
 TFT LCD display
 Model : TFT 850C
2． Suppliers

3． Electrical Parameters
 3.2inch IPS screen
 24V/33V/36V/battery supply
 Rated operating current : 40mA
 Max operating current : 100mA (36V battery, with USB equipment changed)
 USB changing port : 5V 500mA
 Off leakage current < 1uA
 Max output current to controller : 100mA
 Operating temperature : -20～70℃, Storage temperature : -30～80℃
4． Dimensions & Material
 Product shell is ABS, transparent window is made with high strength Acrylic.
 Dimensions : host/L92mm*W60mm*H14mm
