Outer diameter/deformation measurement an extrudate Outer diameter measurement of a part
Gap measurement between rollers Diameter check of press cutting
Abnormal diameters and deformations can
be detected in real time by measuring a
tube at two axes. The 980 µs high-speed
sampling detects even tiny abnormalities.
The thickness of a product can be
controlled by measuring the gaps of the
two sides between the rollers.
Outer Diameter/Width Measurement Mode
+
Calculation function
Easy measurement with the calculation function
A-B:
B :
Deformation measurement
Outer diameter measurement
Easy measurement with the calculation function
A−B=0 A−B≠0
9
Inner Diameter/Gap Measurement Mode
+
Calculation function

Other manuals for Keyence IG Series

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Keyence IG Series and is the answer not in the manual?

Keyence IG Series Specifications

General IconGeneral
Protection RatingIP67
TypeLaser Displacement Sensor
Light SourceSemiconductor laser
OutputAnalog voltage output, Analog current output
Measurement PrincipleTriangulation
Laser TypeClass 2 (IEC/EN 60825-1)
Power Supply12 to 24 VDC
Operating Temperature0°C to 50°C
