8.3 Motor Driving
1) Description
The micro:bit robot shield has a built-in TB6612FNG chip. When using, you just need to insert the micro:bit main
board into the shield, and send the test code to micro:bit main board. Insert well the 18650 battery into the
shield to control the two motors rotate, thus control the micro:bit car run.
Below is a table of TB6612FNG chip pins (PWM range of 0~1023)
