Set the MATERIAL button on front panel to CO2 100% Fe or Ar 75% CO2 25% Ss(Ar 80% CO2
20% also works on this program).
Set the WIRE button on front panel to .023'', .030'' or .035'' refer to the wire used in machine.
Make sure the V type roller used and steel liner of torch used for Stainless Steel welding.
Adjust MENU knob to set the welding ampere according to welding chart.
Press the MENU button to enter specifications of MIG, 2T/4T(2steps or 4steps of welding), set the
value of IND(inductance), HS(Hot start) and BBT (Burn Back Time). (Recommend to use Default
Value)
Remove the tips, press and hold INCHING button, till the wire come out of torch neck.
Fasten the tips according to correct wire diameter(.023'' 0.6mm/.030'' 0.8mm/.035'' 0.9mm) and
Nozzle.
Set the V button on front panel, the voltage can slightly change from -5 to +5(each 1 value=0.3V,
minus 1.5V~plus 1.5V). Wire feed speed can not be adjusted.
C - Ar 75% Co2 25%(Ar 80% Co2 20%) Solid Wire Stainless Steel Welding
S MIG-Synergic Carbon Steel, Gasless .035''
Set the MODE button on front panel to S MIG( ),(once the user sets the welding ampere, the
voltage and wire feed speed will be auto fitted by welder data program(Recommended for skilled
and beginner welders)
Set the MATERIAL button on front panel to .
Note: .035'' wire is only available on Gasless MIG welding.
Make sure the type V-knurled roller used and Steel liner of torch used for Carbon steel welding.
Adjust MENU knob, set the welding ampere according to welding chart.
Press the MENU button to enter specifications of MIG, 2T/4T(2steps or 4steps of welding)
set the value of IND(inductance),HS(Hot start) and BBT (Burn Back Time).(Recommend to use
Default Value)
Remove the tips, press and hold INCHING button, till the wire comes out of torch neck.
Fasten the tips according to correct wire diameter(.023 0.6mm/.030 0.8mm/.035 0.9mm) and
Nozzle.
Set the V button on front panel, and then the voltage can slightly change from -5 to +5(each 1
value=0.3V,Reduce 1.5V~Add 1.5V),Wire feed speed can not be adjusted.
D - 100% Argon Gas Aluminum Steel Welding with U type Roller and Teflon Torch Liner.
S MIG-Synergic Aluminum steel,100% Argon Gas .035/.045''
Set the MODE button on front panel to S MIG( ),(user set the welding ampere, the voltage and
wire feed speed will be auto fitted by welder data program(Recommend for skilled and beginner
welders)
Set the MATERIAL button on front panel to .
Set the WIRE button on front panel to .035 or.045'' refer to the wire used in machine.
Make sure the U type roller used and Teflon liner of torch used for Aluminum & Steel welding.
Adjust MENU knob, set the welding ampere according to welding chart.
Press the MENU button to enter specifications of MIG, 2T/4T(2steps or 4steps of welding)
Set the value of IND(inductance),HS(Hot start) and BBT (Burn Back Time).(Recommended to use
Default Value)
Remove the tips, press and hold INCHING button, till the wire comes out of torch neck.
Fasten the Marked ‘A’(Aluminum)tips according to correct wire diameter(.035'' 0.9mm/.045''
1.2mm) and Nozzle.
Set the V button on front panel, the voltage can micro change from -5 to +5(each 1
value=0.3V,minus 1.5V~plus 1.5V). Wire feed speed can not be adjusted.
