LAB 1: Turn on the LED and Measure LED Current (continued)
c. Press to stop making measurements periodically.
4. Turn off the channel output
a. Press to edit Channel 1 Source value, and then enter 0 V to set
Source value to 0 V.
b. Press Ch1 to turn off Channel 1 Output relay.
“Auto” indicator is
turned off
(1) Press Source (2) Enter 0 V
Page 6
