2 Verification and Adjustments
70 Keysight E36200 Series Service Guide
Current readback accuracy
11 Record the current returned by the SCPI command query via the Keysight
Connection Expert in the “Test Record Forms” on page 74, and verify whether
it is within the limits calculated.
Step Front panel SCPI
10 MEAS:CURR?, (@<channel>)
This is an example for the E36234A,
MAX V, 5 A output.
Table 2-8 Current programming and readback accuracy instrument settings
Model
DUT settings Programming accuracy Readback accuracy
Voltage (V) Current (A) Lower limit Upper limit Lower limit Upper limit
E36231A /
E36233A
MAX 0 –0.006 A 0.006 A –0.006 A 0.006 A
MAX 20 19.974 A 20.026 A –0.026 A 0.026 A
E36232A /
E36234A
MAX 0 –0.003 A 0.003 A –0.003 A 0.003 A
MAX 10 9.987 A 10.013 A –0.013 A 0.013 A
