Service and Maintenance 1
Keysight E36200 Series Service Guide 23
3 Remove the top panel. Slide the top panel
towards the rear and lift it up.
4 Remove the IO board thermal pad.
5 Remove four Pozi screws from the front panel
using a PZ1 driver (two screws on each side).
Step Instructions Visuals
