Service and Maintenance 1
Keysight E36200 Series Service Guide 29
18 Lift and remove the PCA mainboard from the
chassis.
Take caution not to bend any of the connector pins on the
IO board.
Ensure that the two thermal pad are present on the PCA
mainboard before proceeding with the next step.
Step Instructions Visuals
